EFFICIENT
Less consumption
Designed to use minimal energy, these dryers help reduce operational costs while maintaining high-quality air treatment.
Purity
Clean and dry air
Efficient moisture removal prevents corrosion and wear, extending equipment lifespan and ensuring consistent performance.
Compactness
Easy installation
Small footprint allows easy installation in tight spaces, offering versatility for any setup.
Smart condensate management
The ADQ range comes with a smart condensate drain system that uses sensors to remove water without losing any compressed air. This means you save energy while keeping your system running quietly and efficiently.
By only getting rid of the water, it helps reduce waste and keeps your air network clean with minimal effort.
Why Choose the ADQ range?
The ADQ refrigerant dryers combine reliability, efficiency and simplicity in one compact design. They are easy to fit into any setup and keep your equipment safe by removing moisture effectively. With energy-saving features, you’ll also cut down on costs, making it a smart choice for your business.
For clean, dry air you can count on, the ADQ range is the way to go.
- Electronic control panel (ADQ 21-1080/ ADQ 1440-7200)
Provides real-time monitoring of dryer status and dew point display for easy operation.
- Microchannel condenser (ADQ 21-1080/ ADQ 1440-7200)
Best-in-class microchannel refrigerant condenser lowers gas charge, and therefore your carbon footprint.
- Hot gas bypass valve (ADQ 21-1080/ ADQ 1440-7200)
Ensures smooth operation by preventing ice formation under varying load conditions.
- Air/refrigerant heat exchanger (ADQ 21-1080/ ADQ 1440-7200)
Maximises thermal exchange with minimal pressure loss for efficient performance.
- Condensate separator (ADQ 21-1080/ ADQ 1440-7200)
Effectively removes moisture from the system, protecting your compressed air network.
- Motor-driven fan (ADQ 21-1080/ ADQ 1440-7200)
Ensures efficient cooling of the refrigerant condenser for consistent operation.
- Refrigerant compressor (ADQ 21-1080/ ADQ 1440-7200)
Protected against thermal overload, driving the system’s refrigerant circuit.
- Bypass valve (ADQ 21-110)
Allows operation using filters only during maintenance or malfunction, reducing downtime.
- Filter support (ADQ 21-110)
Provides the option to install two filters on the rear side of the dryer, reducing installation costs and overall dimensions.
- Free contacts (ADQ 5940/ ADQ 7200 and standard for ADQ 600-1080)
Offers remote start/stop, general alarm, and drain alarm functions for additional control.
- Control panel with free contacts
Available as an option to monitor alarms such as high/low dew point, fan probe failure, and high refrigerant temperature.
LUAȚI LEGĂTURA CU NOI!
Cu atât de multe produse de tratare a aerului disponibile, găsirea soluției potrivite poate părea dificilă. Specialiștii noștri sunt aici pentru a simplifica procesul și pentru a livra opțiuni care se potrivesc exact cerințelor dumneavoastră. Contactați-ne pentru sfaturi de specialitate și recomandări personalizate.
Technical data
POwer consumption
8260
Built for efficiency, the ADQ dryers consume minimal power, ranging from 130W to 8260W, cutting energy costs without sacrificing performance.
capacity
5040
With capacities ranging from 21 to 5040 m³/h, these products are versatile enough to handle varying air treatment needs, ensuring consistent air quality.
PRESSURE
16
This range operates at a maximum pressure of up to 16 bar, ensuring reliable performance even in demanding environments.
| Model | Power Consumption (W) | Max. Pressure (bar) | Capacity (m³/h) | Weight (kg) |
| ADQ 21 | 130 | 16 | 21 | 19 |
| ADQ 36 | 164 | 16 | 36 | 19 |
| ADQ 72 | 266 | 16 | 72 | 25 |
| ADQ 5040 | 8260 | 14 | 5040 | 810 |
| ADQ 312 G | 933 | 14 | 312 | 64 |
| ADQ 462 G | 1276 | 14 | 462 | 92 |
| ADQ 1080 G | 2629 | 14 | 1080 | 176 |
For full technical specification and more information refer to product brochure
